Heating Cable For Thermocouple And Instrument Machine Connection

Quick Details:

Type: K/N/E/J/T/S/R/B

Place of Origin: Zhejiang, China (Mainland)

Accuracy: I-0.4%t, II-0.75%t, III-1.5%t

Core number: Single / Double

Insulator: 99.6% high purity MgO

Certificate:ISO9001, IATF16949, CE

Application: connecting with thermocouple and instrument machine

Conductor material: NiCr-NiSi, NiCrSi-NiSi, NiCr-Konstantan, Fe-Konstantan, Cu-Konstantan

Sheath material: Inconel600, 0Cr18Ni10Ti, SS304S,SS316L, SS310,SS316,GH3030, GH3039, GH747

Sheath Dia(mm): 0.5mm to 12.7mm :φ0.5,φ1.0, φ1.5(1.6), φ2.0, φ3.0(3.2),φ4.0,φ5.0(4.8),φ6.0(6.4),φ8.0,φ12.7

Type for Sheath Wire Type K:

Different temperature measuring media and service conditions have an impact on the service life and temperature range of armored thermocouples, the data in the table is only recommended data.

Accuracy for Sheath Wire Type K

About this product:

1. 1mm Single Core:

Diameter: The cable has a 1mm diameter single core, indicating that it has one conductive wire inside. This is typical for heating cables where space is constrained or where a simple heating element is required.

2. Mineral Insulated:

Type of Insulation: Mineral insulated cables utilize a solid mineral insulation material (often magnesium oxide) around the conductor. This design allows for high temperature resistance, durability, and safety in harsh environments, making them suitable for use in applications that require high heat or exposure to corrosive substances.

3. Heating Cable:

Function: The primary function of a heating cable is to provide heat through electrical resistance. When an electrical current passes through the conductor, it generates heat, which can be used for various heating applications such as freeze protection, process heating, or maintaining temperatures in pipes or tanks.

4. Inconel 600:

Material: Inconel 600 is a nickel-chromium alloy known for its high-temperature strength and oxidation resistance. This material is often used in harsh environments, including high-temperature applications, due to its excellent resistance to oxidation and carburization.

5. SS310:

Material: SS310 (also known as 310 stainless steel) is a type of stainless steel that is highly resistant to oxidation and can withstand high temperatures. It is typically used in applications where heat resistance is critical, such as in furnace components and heat exchangers.

Type N:

This designation usually refers to a specific type of thermocouple or may indicate a specific application or standard related to the heating cable. It's important to verify the exact meaning depending on the context of your project.

Applications:

Industrial Heating: Used in applications requiring temperature maintenance, such as pipelines, vessels, and tanks.

Freeze Protection: Often employed in outdoor settings to prevent freezing of pipes and other equipment.

Process Heating: Used in various manufacturing processes that require controlled heating.

Considerations:

Voltage and Power Rating: Ensure that the heating cable is rated for the voltage and power requirements of your specific application.

Installation Environment: Confirm that the materials used can withstand the environmental conditions (temperature, chemicals, moisture, etc.) of the intended installation site.

Regulatory Compliance: Ensure compliance with relevant safety standards and regulations for electrical heating systems.

Applications :

• Solid waste incinerators
• Sintering powdered metals
• Firing ceramic materials
• Gas or oil fired furnaces
• Fuel fired heat exchangers
• Box furnaces
• Nuclear or hydrocarbon based energy plants
• And many more...

Product Pictures

Company Information:

A. Main Products

B. Package

We add heat shrink tubing and plastic film to make sure high insulated resistance.

Except marking notes, we also have pass card and test report for every coil cable.

C. Mi cable Production line

We have high - quality professional products, as well as advanced product lines and equipments. All of the products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.Along the increasing market demands, we continuously satisfy customers by updating products to improve prouduction systems, improve quality.

Order Notice:

1. Accurate quotation.

2. Confirm the price, trade term, lead time, payment term etc.

3. LEADKIN sales send the Proforma Invoice with LEADKIN seal.

4. Customer arranges the payment for deposit and sends us bank slip.

5. Middle Production-send photos to show the production line which you can see your products in . Confirm the estimated delivery time again.

6. End Production-Mass production products photos.

7. Clients make payment for balance and LEADKIN ships the goods. Inform the tracking number and check the status for clients.

8. The order is finished perfectly when you receive the goods and get satisfied with them .

9. Feedback to LEADKIN about Quality , Service, Market Feedback & Suggestion. And we will do better .
