0.3mm 9.5mm SS310 K Type Thermocouple Cable 1.5 Mm Single Core Cable 99.6 Percent MgO

Product Categories
Ningbo Leadkin Instrument Complete Sets of Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

0.3mm 9.5mm SS310 K Type Thermocouple Cable 1.5 Mm Single Core Cable 99.6 Percent MgO

Brand Name : LEADKIN

Model Number : LK-E

Certification : ISO,CE

Place of Origin : NINGBO CHINA

MOQ : 100M

Price : USD 1.2-6.5/M

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1,000,000M/year

Delivery Time : 2-7 working days

Packaging Details : 68*68*8cm Carton

Name : 9.5mm four conductors Mineral Insulated Thermocouple Cable SS310 Type K

Dia. : 0.5-12.7mm

Type : E

Purity of Mgo : more than 99.6%

Package : Carton. Pallet

Jacket : stainless steel

MOQ : 50M

Color : white

Contact Now

9.5mm four conductors Mineral Insulated Thermocouple Cable SS310 Type K

Quick Details:

Name:9.5mm four conductors Mineral Insulated Thermocouple Cable SS310 Type K

Conductor material: NiCr-NiAl

Insulator: 99.6% high purity MgO

Dia(mm): 0.3mm to 12.7mm

Core: single and double

Type for Sheath Wire Type K

Product Name Code Type Shaeth Material Outside Dia. Temperature
NiCr-NiSi /NiCr-NiAl KK K SS304 SS316 0.5-1.0 400
1.5-3.2 600
4.0-8.0 800
SS310 Inconel600 0.5-1.0 500
1.5-3.2 800
4.0-6.4 900
8.0-12.7 1000
NiCrSi-NiSi NK N SS304 SS316 0.5-1.0 400
1.5-3.2 600
4.0-8.0 800
SS310 Inconel600 0.5-1.0 500
1.5-3.2 800
4.0-6.4 900
8.0-12.7 1000
NiCr-Konstantan EK E SS304 SS316 0.5-1.0 400
1.5-3.2 600
4.0-8.0 800
Fe-Konstantan JK J SS304 SS316 0.5-1.0 400
1.5-3.2 600
4.0-8.0 800
Cu-Konstantan TK T SS304 SS316 0.5-1.0 400
1.5-3.2 600
4.0-8.0 800
RhPt10-Ph SK S Inconel600 6.0-12.7 1100

Accuracy for Sheath Wire

Type Class I Class II
Accuracy Temp.Range Accuracy Temp.Range
K ±1.5℃ -40~375℃ ±2.5℃ -40~375℃
±0.4% 375℃-1000℃ ±0.75% 375℃-1000℃
N ±1.5℃ -40~375℃ ±2.5℃ -40~375℃
±0.4% 375℃-1000℃ ±0.75% 375℃-1000℃
E ±1.5℃ -40~375℃ ±2.5℃ -40~375℃
±0.4% 375℃-800℃ ±0.75% 375℃-800℃
J ±1.5℃ -40~375℃ ±2.5℃ -40~375℃
±0.4% 375℃-800℃ ±0.75% 375℃-800℃
T ±0.5℃ -40~125℃ ±1.0℃ -40~125℃
±0.4% 125℃-350℃ ±0.75% 125℃-350℃
S 0-1100℃ ±1.0℃ 0-1100℃ ±1.5℃

Product Pictures

0.3mm 9.5mm SS310 K Type Thermocouple Cable 1.5 Mm Single Core Cable 99.6 Percent MgO

0.3mm 9.5mm SS310 K Type Thermocouple Cable 1.5 Mm Single Core Cable 99.6 Percent MgO

Company Information:

A. Main Products

0.3mm 9.5mm SS310 K Type Thermocouple Cable 1.5 Mm Single Core Cable 99.6 Percent MgO

B. Invention Patent :Manufacturing method of sheath thermocouple cable

Usage:Raw material of sheath thermocouple

0.3mm 9.5mm SS310 K Type Thermocouple Cable 1.5 Mm Single Core Cable 99.6 Percent MgO

C. Warehouse

We have great amount mi cable in stock. We expecting your visiting.

0.3mm 9.5mm SS310 K Type Thermocouple Cable 1.5 Mm Single Core Cable 99.6 Percent MgO

FAQ:

1. Accurate quotation.
2. Confirm the price, trade term, lead time, payment term etc.
3. LEADKIN sales send the Proforma Invoice with LEADKIN seal.
4. Customer arranges the payment for deposit and sends us bank slip.
5. Middle Production-send photos to show the production line which you can see your products in . Confirm the estimated delivery time again.
6. End Production-Mass production products photos.
7. Clients make payment for balance and LEADKIN ships the goods. Inform the tracking number and check the status for clients.
8. The order is finished perfectly when you receive the goods and get satisfied with them .
9. Feedback to LEADKIN about quality, service, market feedback & suggestion. And we will do better .
